HONPINE single- and dual-encoder robot joint modules are compatible with communication protocols such as CAN, CANopen, and EtherCAT
In the field of robot joint modules, encoders are crucial components, and communication protocols are the "language" that enables encoders to work efficiently with other devices. Our joint modules support both single and dual encoders and are compatible with multiple communication protocols, including CAN, CANopen, and EtherCAT. Today, we will provide a detailed introduction to these protocols.
CAN Protocol
CAN (Controller Area Network) is a serial communication protocol bus designed for real-time applications. It offers high reliability, strong anti-interference capabilities, and adaptability to complex electromagnetic environments, making it widely used in industrial control, automotive electronics, and other fields. In our joint modules, the CAN protocol ensures stable data transmission. For example, when a robot is operating in a factory environment, surrounded by numerous electrical devices, the CAN protocol ensures accurate transmission of encoder data to the control unit, enabling precise control of joint motion.
CANopen Protocol
CANopen is an application-layer protocol developed based on the CAN protocol. It provides unified communication specifications for devices from different manufacturers, greatly improving system compatibility and interoperability. Using the CANopen protocol in robotic joint modules allows engineers to easily integrate our joint modules into various complex robotic control systems. For example, in multi-joint collaborative robots, each joint module uses the CANopen protocol to quickly and accurately receive commands from the main controller and coordinately perform various complex movements.
EtherCAT Protocol
EtherCAT (Ethernet for Control Automation Technology) is a high-performance industrial Ethernet communication protocol. It offers extremely high real-time performance, synchronization accuracy, and fast data transmission. For robotic applications requiring extremely high motion control accuracy and real-time performance, such as precision assembly tasks in collaborative robots, the EtherCAT protocol enables dual encoders to quickly provide precise feedback on joint position and velocity, enabling robots to execute tasks with sub-millisecond response speeds and achieve high-precision operations.
Whether single or dual encoder, CAN, CANopen, and EtherCAT protocols play a key role in our joint modules. They provide strong support for the efficient and precise operation of robots and meet the diverse needs of robot joint control in different application scenarios.
